- High Performance Mica Insulation Products
- 950℃ refractory insulation
- Has strong viscosity and tensile strength
- Good high temperature resistance and combustion resistance
- Good insulation in flame combustion and high temperature
Products
High-Temperature Mica Insulating Tape
950 C flame-resistant mica tape with adhesive backing for EV battery packs
Product Details
Product Details
High-Temperature Mica Insulating Tape
Mica insulating tape for EV battery packs, supplied with adhesive on one side so it bonds tightly to the substrate. The tape resists a 950 °C flame for 10 minutes without burn-through.
It can be laminated with PET or PI film and meets RoHS requirements. Widths from 20 mm to 1000 mm are available on request.
Requirements
Technical requirements
- Fire resistance: no burn-through after 10 minutes in a 950 °C flame.
- Withstand voltage: 10 minutes at 950 °C, then 5000 VDC for 1 minute without breakdown.
- Adhesion: adhesive on the mica side, bonding tightly to the substrate; no breakdown at 5000 VDC under pressure.
- Lamination: can be combined with PET film or PI film.
- Compliance: meets RoHS requirements.
Specifications
Specifications
| Property | Specification |
|---|---|
| Width | 20 mm, 25 mm, 30 mm–1000 mm |
| Length | 20 m/roll, 50 m/roll, custom lengths available |
Need this part to your drawing?
Send us the pack layout, the working temperature and the test you are working to, and we will confirm the material, the adhesive and the tooling route.
